OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale

OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale

Large Image :  OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale

Product Details:
Place of Origin: Jiangsu, China
Brand Name: FIVESCALES
Model Number: Truck Scale
Payment & Shipping Terms:
Minimum Order Quantity: 5 pieces
Price: $6,500.00/pieces 5-5 pieces
Packaging Details: Standard wooden cases are used to prevent product damage
Supply Ability: 500 Piece/Pieces per Month
Contact Now

OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale

Description
Warranty: 5years Customized Support: OEM, ODM
Power Supply: 220v/50Hz Display Type: LED
Capacity: 10-250T Accuracy Level: OIML(III)
Relative Humidity: <95% Safety Overload: 125%F.S
Degree Of Protection: IP68 Level Weighbridge Platform Width: 3 Meter -4 Meter
Length Of Weighbridge Platform: 9 Meter -26 Meter Maximum Capacity: 30 Ton -300T On
Port: Shanghai ,ningbo

Product Description
  heavy duty weighing scale
Platform size
3*10M, 3*12M, 3*14M, 3*16M ,3*18m ,can be ordered
Capacity
60T,80T,100T,120T,150T,200T ,can be ordered
Accuracy Class
OIML  Ⅲ
Safe Overload
125%f.s
Limit Overload
150%F.S
Scale Structrue Form
Modular Structure
Temperature Range
20°C ~ 50°C
Accuracy
5KG/10KG/20KG/50KG
Division Value
5KG/10KG/20KG

OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 0
FIVESCALES weighbridge scale
High strength steel plate
Thickness of 10mm, 12mm, 14mm, 16mm or customized
Chequer plate optional
Safety load: 150% with OIML, CE, NTEP certificates
FIVESCALES weighbridge scale
Thickened U shape beams, each equipped with 6pcs, and 1 in middle specially for exporting
Eco-friendly epoxy zinc rich painting material
passing the International standard, Anti rust and anti corrosion, to make sure its safety
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 1
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 2
FIVESCALES weighbridge scale
weighing indicator, widely used.
AC, DC can be used, simple maintenance, strong anti-jamming
FIVESCALES weighbridge scale
KELI brand load cells, or ZEMIC optional.
With high accuracy, good longterm stability.
Each equipped with 4pcs, 6pcs, 8pcs, 12pcs load cell depend on size
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 3

Introduction of Production Process

OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 4 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 5

1.Laser cutting

 2.Bending u-beam(max. thickness 10mm)
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 6 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 7
2.Bending Machine bending u-beam 2.1. u-beam(max. thickness 10mm)for example
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 8 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 9
3.Pre-assembling 4.Automatic welding of u-beams
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 10 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 11
5.Test on every part 6.1.Side plate welding by Robot
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 12 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 13
6.2.Welding  6.3.Side plate welding by Robot
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 14 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 15
7. Bridge deck finishing 8.Polishing on work pieces
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 16 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 17
9.1. Pre-assembling before shot-blasting 9.2.Pre-assembling before shot-blasting
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 18 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 19
10.1.Shot-blasting 10.2.Pre-assembling before shot-blasting
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 20 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 21
11.1.High quality painting in dust-free room 11.2.Stoving varnish for every painted work piece which greatly improves rust protection performance and shortens lead time
OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 22 OIML III Accuracy Level Electronic Weighbridge Truck Scale 30-300 Ton Heavy Duty Scale 23
12. Work piece after stoving varnish 13. Packing & Shipping
